| Quantity: | |
|---|---|
FT-6-10
MACH
8477.8090
210mm*(6 Lanes-10 Lanes)
1100mm
2
PLC
120-180m/min
170-210 x130-210mm
85-105 x 65-105mm V fold
Roots vacuum pump
Pneumatic dot slitting
Alternate stack by stack
| Machine Model | 6 Lanes | 8 Lanes | 9 Lane | 10 Lanes |
| Finished Products Unfolded Size (mm) | 200×200(Other sizes are available) | |||
| Raw Material Diameter (mm) | Φ1100(Other sizes are available ) | |||
| Raw Material Core Diameter (mm) | 76.2mm(Other sizes are available) | |||
| Stable Speed | 120-180m/min | |||
| Programmable controller | PLC Programmable Controller | |||
| Embossing Unit | Steel to rubber , steel to steel | |||
| Bottom Embossing Roller | Felt roller, Paper roller, Rubber roller, steel roller | |||
| Edge Embossing | Steel to steel, independent adjustment | |||
| Automatic Jumbo roll guiding system | Optional | |||
| Slitting unit | Pneumatic dot slitting | |||
| Lubricating system | Automatic key parts regular lubricating | |||
| Driving system | Timing belt driving system | |||
| Counting system | Alternate stack by stack | |||
| Main Motor Power | Frequency conversion speed regulator, 5.5-11 kw | |||
| Vacuum suction unit | 11-32KW | |||
| Pneumatic System | 3 HP air compressor, mini pressure 5kg/cm2Pa(Provided by client) | |||
| Dimension(L×W×H) (mm) | 6370x(1780-2080)x2130 depends on each model | |||
| Weight | 6500-8500kg | |||
| Vacuum suction unit | Roots vacuum pump | |||
| Programmable controller | Delta Programmable Controller (PLC),LCD screen operation panel | |||
| Power | Frequency conversion speed | |||
| regulator, Electromagnetic speed-regulation motor | ||||
| Driving system | Timing belt, chain | |||
| Optional: | ||||
| Embossing Unit | Steel to rubber(by default) , steel to steel, Steel to Wool | |||
| Bottom Embossing Roller | Felt roller, Paper roller, Rubber roller, steel roller | |||
| Slitting unit | Pneumatic dot slitting | |||
| Edge Embossing | Steel to steel, independent adjustment | |||
| Automatic Jumbo roll guiding system | Optional | |||
| Lamination Unit | can be order | |||
| Color Printing Unit | Can be ordered | |||
| Machine Model | 6 Lanes | 8 Lanes | 9 Lane | 10 Lanes |
| Finished Products Unfolded Size (mm) | 200×200(Other sizes are available) | |||
| Raw Material Diameter (mm) | Φ1100(Other sizes are available ) | |||
| Raw Material Core Diameter (mm) | 76.2mm(Other sizes are available) | |||
| Stable Speed | 120-180m/min | |||
| Programmable controller | PLC Programmable Controller | |||
| Embossing Unit | Steel to rubber , steel to steel | |||
| Bottom Embossing Roller | Felt roller, Paper roller, Rubber roller, steel roller | |||
| Edge Embossing | Steel to steel, independent adjustment | |||
| Automatic Jumbo roll guiding system | Optional | |||
| Slitting unit | Pneumatic dot slitting | |||
| Lubricating system | Automatic key parts regular lubricating | |||
| Driving system | Timing belt driving system | |||
| Counting system | Alternate stack by stack | |||
| Main Motor Power | Frequency conversion speed regulator, 5.5-11 kw | |||
| Vacuum suction unit | 11-32KW | |||
| Pneumatic System | 3 HP air compressor, mini pressure 5kg/cm2Pa(Provided by client) | |||
| Dimension(L×W×H) (mm) | 6370x(1780-2080)x2130 depends on each model | |||
| Weight | 6500-8500kg | |||
| Vacuum suction unit | Roots vacuum pump | |||
| Programmable controller | Delta Programmable Controller (PLC),LCD screen operation panel | |||
| Power | Frequency conversion speed | |||
| regulator, Electromagnetic speed-regulation motor | ||||
| Driving system | Timing belt, chain | |||
| Optional: | ||||
| Embossing Unit | Steel to rubber(by default) , steel to steel, Steel to Wool | |||
| Bottom Embossing Roller | Felt roller, Paper roller, Rubber roller, steel roller | |||
| Slitting unit | Pneumatic dot slitting | |||
| Edge Embossing | Steel to steel, independent adjustment | |||
| Automatic Jumbo roll guiding system | Optional | |||
| Lamination Unit | can be order | |||
| Color Printing Unit | Can be ordered | |||
