| Dimensions: | |
|---|---|
| Weight: | |
| Quantity: | |
2-6 lanes
MACH
8477.8090
210mm*(2 Lanes-6 Lanes)
1100mm
2
PLC
70-110m/min/Lane 48,000sheets/hour/lane
170-210 x130-210mm
85-105 x 65-105mm V fold
Driving by Step less gear box
Electronic counting
Two sets steel to rubber embossing
| Item | Specifications |
| Model | 2Lines -6Lines with lamination gluing unit |
| Finished Products Unfolded Size (mm) | 200×200±2mm( other size,like V-170mm--220mm can be ordered also) |
| Jumbo Roll Diameter (mm) | ≤Φ1200mm(Other sizes are available) |
| Inner core Diameter (mm) | 76.2(Other sizes are available) |
| Speed | 0~100m/min |
| Programmable controller | Delta Programmable Controller (PLC) |
| Embossing Unit and lamination gluing unit | Steel to Rubber embossing,lamination glue unit can be controlled automatically by PLC Or hand valve ,and glue volume can be easily adjusted |
| Slitting unit | Pneumatic dot slitting blades,cutters distance/width can be adjustable |
| Driving system | Timing belts, chains |
| Counting system | Automatic counting,sensors |
| Main Motor Power | Frequency conversion speed regulator, 5.5-11 kw,depends on model |
| Vacuum suction unit | 11-32KW (Depending on the specification and the tissue quality ) |
| Pneumatic System | 3 HP air compressor, mini pressure 5kg/cm2 Pa(Provided by client) |
| Dimension(L×W×H) (mm) | 7980x1780x2320 depends on the model |
| Weight | 4500kg -7500kg depends on model |
| Programmable controller | Delta Programmable Controller (PLC) |
| Driving system | Timing belts, chains |
| Option | |
| Edge-line Embossing | Steel to steel,can be ordered |
| Printing unit | Flex graphic printing, 1-2 color |
| Item | Specifications |
| Model | 2Lines -6Lines with lamination gluing unit |
| Finished Products Unfolded Size (mm) | 200×200±2mm( other size,like V-170mm--220mm can be ordered also) |
| Jumbo Roll Diameter (mm) | ≤Φ1200mm(Other sizes are available) |
| Inner core Diameter (mm) | 76.2(Other sizes are available) |
| Speed | 0~100m/min |
| Programmable controller | Delta Programmable Controller (PLC) |
| Embossing Unit and lamination gluing unit | Steel to Rubber embossing,lamination glue unit can be controlled automatically by PLC Or hand valve ,and glue volume can be easily adjusted |
| Slitting unit | Pneumatic dot slitting blades,cutters distance/width can be adjustable |
| Driving system | Timing belts, chains |
| Counting system | Automatic counting,sensors |
| Main Motor Power | Frequency conversion speed regulator, 5.5-11 kw,depends on model |
| Vacuum suction unit | 11-32KW (Depending on the specification and the tissue quality ) |
| Pneumatic System | 3 HP air compressor, mini pressure 5kg/cm2 Pa(Provided by client) |
| Dimension(L×W×H) (mm) | 7980x1780x2320 depends on the model |
| Weight | 4500kg -7500kg depends on model |
| Programmable controller | Delta Programmable Controller (PLC) |
| Driving system | Timing belts, chains |
| Option | |
| Edge-line Embossing | Steel to steel,can be ordered |
| Printing unit | Flex graphic printing, 1-2 color |
